Enclosure Thermal Management

The Hammond PF 66000 R series reach a particularly high airflow and at the same time provide a Type 3R system of protection with flow optimized fins and rotor blades.

• Airflow rate up to 462 CFM
• System of protection NEMA Type 3R
• Cut-out dimensions: 11.46 x 11.46"
• Color: Light Gray

The Saginaw Type 12 series has an easy to install snap fit design for use in enclosures that require cooling but have limited space in NEMA 1 and 12 applications. Housing and grille are made of black heat resistant (ABS-FR), self-extinguishing material.

• Airflow rate up to 47 CFM
• System of protection NEMA Type 12
• Cut-out dimensions: 5.03 x 5.03"
• Color: Black

The Saginaw Type 3R series has an easy to install snap fit design for use in enclosures that require cooling in NEMA 3R applications. Grille is made of black UV and water resistant, self-extinguishing PVC material, housing is made of ABS material with steel inner guard.

• Airflow rate up to 47 CFM
• System of protection NEMA Type 3R
• Cut-out dimensions: 5.03 x 5.03"
• Color: Black

The Saginaw Type 3R series has an easy to install snap fit design for use in enclosures that require cooling in NEMA 3R applications. Grille is made of black UV and water resistant, self-extinguishing PVC material, housing is made of ABS material with steel inner guard.

• Airflow rate up to 47 CFM
• System of protection NEMA Type 3R
• Cut-out dimensions: 5.03 x 5.03"
• Color: Black

The CR 027 fan heater prevents the formation of condensation and ensures an even temperature in enclosures. The integrated thermostat is used to set the desired temperature while the high performance axial fan provides forced air circulation.

• 20 CFM
• DIN Mounting
• Adjustable Thermostat
• II (double insulated) / IP20
• UL File No. E204590, VDE, EAC

The Hammond PTF GEN4 series enclosure filter fans are made of strong thermoplastic material, heat resistant, UL 94 VO approved and use a patented “Click & Fit” design which provides a hardware free installation.

• Airflow rate up to 485 CFM
• System of protection IP 55, NEMA Type 12
• Cut-out dimensions: 11.46 x 11.46"
• Painted light gray

The Hammond PTF GEN4 series enclosure filter fans are made of strong thermoplastic material, heat resistant, UL 94 VO approved and use a patented “Click & Fit” design which provides a hardware free installation.

• Airflow rate up to 485 CFM
• System of protection IP 55, NEMA Type 12
• Cut-out dimensions: 11.46 x 11.46"
• Painted light gray

The Saginaw Type 3R series has an easy to install snap fit design for use in enclosures that require cooling in NEMA 3R applications. Grille is made of black UV and water resistant, self-extinguishing PVC material, housing is made of ABS material with steel inner guard.

• Airflow rate up to 494 CFM
• System of protection NEMA Type 3R
• Cut-out dimensions: 11.57 x 11.57"
• Color: Black

The Saginaw Type 3R series has an easy to install snap fit design for use in enclosures that require cooling in NEMA 3R applications. Grille is made of black UV and water resistant, self-extinguishing PVC material, housing is made of ABS material with steel inner guard.

• Airflow rate up to 494 CFM
• System of protection NEMA Type 3R
• Cut-out dimensions: 11.57 x 11.57"
• Color: Black

Compact convection heater of temperature class T3 (392 �F / 200 �C max.) for use in hazardous areas for prevention of formation of condensation, temperature fluctuations, and for protection against frost in control and switch cabinets, as well as in measuring equipment.

• Temperature Class T3
• DIN Mounting
• IP66 / I (grounded)
• EPS 16 ATEX 1 109 X IECEx EPS 16.0048X EAC

Compact convection heater of temperature class T3 (392 �F / 200 �C max.) for use in hazardous areas for prevention of formation of condensation, temperature fluctuations, and for protection against frost in control and switch cabinets, as well as in measuring equipment.

• Temperature Class T3
• Screw Mounting
• IP66 / I (grounded)
• EPS 16 ATEX 1 109 X IECEx EPS 16.0048X EAC

Compact convection heater of temperature class T4 (275 �F / 135 �C max.) for use in hazardous areas for prevention of formation of condensation, temperature fluctuations, and for protection against frost in control and switch cabinets, as well as in measuring equipment.

• Temperature Class T4
• DIN Mounting
• IP66 / I (grounded)
• EPS 16 ATEX 1 109 X IECEx EPS 16.0048X EAC
