Resolution
|
640 x 480
|
|
SuperResolution
|
1280 x 960
|
|
Focus Mode(s)
|
TurboFocus system for continuous, laser-assisted, thermal contrast AF, touch AF; Manual focus
|
|
Temp. Measurement Range
|
-4 to 248 F; 32 to 1202 F
|
|
Temp. Measurement Accuracy
|
+/- 1.8 F or +/- 1%, whichever is greater at temp range 32 to 212 F | +/- 3.6 F or +/- 2% for other temp range (ambient temp at 77 F)
|
|
Thermal Sensitivity
|
30mk (0.054 F) @ 86 F
|
|
Frame Rate
|
30Hz
|
|
Field of View (FOV)
|
25 x 19 Deg.
|
|
Acoustic Microphone Channels
|
162 MEMS Digitial Microphone
|
|
Acoustic Image FOV
|
66 x 52 Deg.
|
|
Acoustic Working Distance
|
1 to 328 ft.
|
|
Storage
|
SD Card, Hot-Swappable, Supports up to 1TB
|
|
Software
|
NaviPdM, AnalyzIR (Free unlimited licenses)
|
|
